PTFE Lined Ball Valve Manufacturer in Vapi

Price 2000 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

PTFE Lined Ball Valve Manufacturer in Vapi Specification

Channels
1 / 2

Caliber
Standard

Structure
Full Bore, 2 Piece Design

Connection
Flanged

Pressure
PN 10 / PN 16 / Class 150

Material
PTFE Lined Carbon Steel / Stainless Steel

Power
Manual / Electric / Pneumatic

Media
Acid, Alkali, Water, Gas

Temperature of Media
Up to 180C

Port Size
15mm to 200mm

Flange
ANSI B16.5 / DIN Standard

Finish
Epoxy Painted, Corrosion Resistant

Application
Chemical, Pharmaceutical, Water Treatment

Leakage Class
Class VI (Bubble Tight)

Anti-Static Device
Provided

Seat Material
PTFE / TFM / FEP

Stem Material
SS304 / SS316

Body Coating
Fusion Bonded Epoxy

Testing
Hydrostatic & Pneumatic as per API 598

Corrosion Resistance
High

Handle
Lockable Lever Available

Operation Type
Quarter Turn

Fire Safe Design
Optional

Ball Material
SS316/PTFE Coated

Design Standard
BS EN ISO 17292 / ASME B16.34

End Connection
Flanged as per ASME / ANSI / DIN / JIS

About PTFE Lined Ball Valve Manufacturer in Vapi

Introducing the exceptional PTFE Lined Ball Valve by FlowBiz Export Pvt Ltd! Engineered with precision and innovation, FlowBiz PTFE Lined Ball Valve is a testament to quality craftsmanship and reliable performance. Combining the strength of durable materials with the versatility of PTFE lining, FlowBiz PTFE Lined ball valve ensures exceptional resistance to corrosive fluids and extreme temperatures. Its seamless design guarantees smooth and efficient flow control, while the PTFE lining protects against leaks and contamination.

Trust in FlowBiz PTFE Lined Ball Valve to deliver uncompromising reliability, longevity, and unmatched value for various industrial applications. Elevate your fluid handling systems with FlowBiz Export Pvt Ltd's unmatched expertise and the unrivaled performance of our PTFE Lined Ball Valve.

Mesh Material: PTFE, PFA AND FEP

Size: Up to 6 Inch (15mm to 300mm)

Pressure Rating: 300 Class

End Connection: Flanged End

key features of PTFE Lined Ball Valve:

Superior Corrosion Resistance

High-Temperature Capability

Leak-Free Operation

Smooth and Precise Flow Control

Versatile Application Range

Durability and Longevity

Easy Installation and Maintenance

Advanced Corrosion Resistance

The PTFE lining and epoxy coating provide superior protection against aggressive chemicals, acids, and alkalis. Our valves are crafted with stainless steel and carbon steel bodies, ensuring durability and long service life even in challenging industrial environments. This makes them suitable for applications where corrosion resistance is essential.

Strict Quality and Testing Standards

Every PTFE Lined Ball Valve undergoes rigorous hydrostatic and pneumatic testing as per API 598 standards. Designed in compliance with BS EN ISO 17292 and ASME B16.34, we guarantee reliability, safety, and performance, meeting global industry requirements for leak-proof and bubble-tight operation. Optional fire safe designs are also available for enhanced safety measures.

Versatile Operational Features

Our valves are equipped for quarter-turn operations, with options for manual, electric, or pneumatic actuation. The flanged end connections meet international standards (ANSI, DIN, JIS), allowing easy installation and integration. Lockable levers provide secure handling, and anti-static devices ensure safety in volatile environments. Full bore, two-piece design supports efficient flow and easy maintenance.

FAQ's of PTFE Lined Ball Valve Manufacturer in Vapi:

Q: How does the PTFE lining in your ball valves benefit chemical and pharmaceutical applications?

A: The PTFE lining offers exceptional chemical resistance, preventing corrosion and contamination when handling aggressive acids, alkalis, and solvents. This ensures reliable performance, long service life, and safe fluid control in highly demanding chemical and pharmaceutical environments.

Q: What materials are used for the ball, seat, and stem in these ball valves?

A: Our ball valves feature balls made from SS316 stainless steel or with a PTFE coating. The seats are manufactured from PTFE, TFM, or FEP, offering superb sealing and chemical resistance. The stems are crafted from SS304 or SS316, providing robust mechanical strength and durability.

Q: Where are these PTFE lined ball valves typically installed?

A: These valves are widely used in chemical processing plants, pharmaceutical industries, water treatment facilities, and environments requiring corrosion protection. Their flanged connections make them compatible with piping systems built to ASME, ANSI, DIN, or JIS flanged standards.

Q: What is the process for quality assurance and testing of these valves?

A: Each valve undergoes hydrostatic and pneumatic testing as per API 598, ensuring bubble-tight (Class VI) leakage performance. Design compliance with BS EN ISO 17292 and ASME B16.34 guarantees consistency, safety, and adherence to global standards during manufacturing.

Q: How is the valve operated and what types of handles are available?

A: These ball valves provide quarter-turn operation and can be actuated manually with a lockable lever, or through electric or pneumatic actuators. The lockable handle increases operational security and prevents accidental valve movement during critical processes.

Q: What are the advantages of using a fusion bonded epoxy coating on the valve body?

A: Fusion bonded epoxy coating offers enhanced protection against corrosion, extending the valve's lifespan and reliability under harsh conditions. This finish further improves resistance to chemicals and environmental stress, making it suitable for industrial use.

Q: Can you supply and export PTFE lined ball valves in different pressure classes and port sizes?

A: Yes, we manufacture, supply, and export PTFE lined ball valves in pressure classes PN 10, PN 16, and Class 150. Port sizes range from 15mm to 200mm, allowing for flexibility in pipelines and diverse application requirements.
