Audco Cast Iron Plug Valve

About Audco Cast Iron Plug Valve

Specification:

Class 125 flange dimensions and drilling in accordance with ANSI B 16.1 BSPT D AND F flange dimensions and drilling in accordance with BS10.

These valves have a port area substantially equal to the bore of pipe where full area is not essential economies can be made by the use of short pattern valves having reduced area.

Product Name: AUDCO Make CI Plug Valve (Light Duty)

Figure Number: IN123

Size Range: 15mm  50mm ( 1/2 Inch to 2 Inch)

Pressure Rating: 125 Max Working Pressure

Material: Cast Iron

End Connection: Screwed End.

Product Name: AUDCO Make CI Plug Valve (Heavy Duty)

Figure Number: MW12

Size Range: 15mm  40mm ( 1/2 Inch to 1 1/2 Inch)

Pressure Rating: 150 Max Working Pressure

Material: Cast Iron

End Connection: Screwed End.

Product Name: AUDCO Make CI Plug Valve (Long Pattern)

Figure Number: MW11/F/13

Size Range: 15mm  200mm ( 1/2 Inch to 8 Inch)

Pressure Rating: 150 Max Working Pressure

Material: Cast Iron

End Connection: Flanged End.
