5/3 Double Solenoid Valve With Spring Center

Name: 5/3 Double Solenoid Valve With Spring Center
Brand: FLOWBIZ EXPORTS PRIVATE LIMITED
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Number

Get a Price/Quote

MOQ : 1 Unit

5/3 Double Solenoid Valve With Spring Center Specification

Features
Double solenoid with spring return center

Material
Aluminum and engineering plastic

Valve Size
Standard small size

Control System
Solenoid

Connection Type
Threaded

Valve Type
5/3 closed-center valve

Application
Pneumatic systems

Voltage
24V DC or 110V AC

Structure
Compact modular design

Sealing
High durability elastomers

Type
Directional control valve

Power
Electromagnetic

Pressure
0.15 to 0.8 MPa

Media
Compressed air

Port Size
1/4\

Temperature
-5 to 50°C

Disc
Spring Center

Pin
5/3 configuration

5/3 Double Solenoid Valve With Spring Center About

Model Information

Type : Solenoid Operated, Lever Operated, Pilot Air Operated,

Push Pull (3X2, 5X2, 5X3 & NC / NO)

Design : Spool With Cartridge Type

Media : Compressed Air (Filtered & Lubricated)

Working Pressure Range : 2 - 10 Bar

Ambient / Media Temperature : 5C - 60C

Media : Aluminium, Nitrile, Brass, Polymer

Coil Information

Coil Width : 26 mm

Coil Bore : 10 mm

Voltage (V) 10 : AC (50Hz, 60Hz) - 24V, 110V, 230V

DC 12V, 24V, 36V, 48V, 110V

Power Consumption : AC-6W, DC-6W

Duty Cycle : Continuous

Class of Insulation : Class H

Type of Coil Protection : IP65

Compact Modular Design for Versatile Installation

The 5/3 Double Solenoid Valve showcases a compact, modular design that allows seamless integration into diverse pneumatic setups. Its standardized small size and threaded connections make installation quick and adaptable, fitting into both new and retrofit applications with ease.

Superior Materials for Durability

Crafted from high-quality aluminum and engineering plastic, this valve ensures strength and longevity in demanding environments. Coupled with durable elastomeric seals, the design maintains optimal performance and minimizes downtime due to wear or leakage.

Reliable Performance Under Variable Conditions

Operating across a broad temperature and pressure spectrum, this valve suits varied industrial environments. The dual solenoid with spring center configuration delivers precise control, while the high-quality construction supports consistent operation in applications from automation to manufacturing.

FAQ's of 5/3 Double Solenoid Valve With Spring Center:

Q: How does the 5/3 Double Solenoid Valve with Spring Center function in pneumatic systems?

A: This valve uses two solenoids and a spring-centered disc to control the direction of compressed air. When neither solenoid is energized, the spring returns the disc to a center (closed) position, blocking all ports and stopping airflow, which is useful for safe and precise pneumatic system control.

Q: What are the main benefits of using a 5/3 closed-center valve in automation?

A: The closed-center configuration allows all ports to be blocked in the center position, preventing unintended actuator movement and pressure loss. This improves safety, offers versatile control for complex automation scenarios, and helps maintain system pressure during idle states.

Q: When should I opt for the 1/4-inch port size with this valve?

A: A 1/4-inch port size is ideal for standard pneumatic circuits where moderate airflow is sufficient. It provides a balance between compactness and flow capacity, fitting most small-to-medium scale industrial and automation setups.

Q: Where can this compact directional control valve be installed?

A: Thanks to its modular and threaded design, the valve is suitable for installation in varied pneumatic control panels, machines, and integrated automation lines. Its compact size enables it to fit in tight spaces, supporting both standalone and multi-station manifolds.

Q: What is the process for wiring and controlling the solenoids of this valve?

A: The solenoids can be connected to either a 24V DC or 110V AC control circuit, depending on your system's requirements. Control signals to each solenoid shift the valve spool left or right, while de-energizing both returns the spool to the center, effectively closing all flow paths.

Q: How does the high-durability elastomer sealing enhance long-term usage?

A: The elastomeric seals resist wear and deformation from repeated cycling and varying temperatures, minimizing leakage and maintaining performance. This leads to reduced downtime, lower maintenance costs, and extended service life in pneumatic applications.
