Knife EDGE Gate Valve Manufacturer in India

Price 1500 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

Knife EDGE Gate Valve Manufacturer in India Specification

Size
2 to 48 (DN50 to DN1200)

Sealing
Soft/Metal Seated

Voltage
24V, 110V, 220V, 415V (for actuated models)

Connection
Flanged / Wafer / Lug

Structure
Single / Double Gate

Material
Stainless Steel / Carbon Steel / Alloy Steel

Type
Knife Edge Gate Valve

Power Source
Manual, Pneumatic, Electric Actuator

Pressure
Up to 20 Bar

Media
Slurry, Powder, Liquids, Solids

Working Temperature
Up to 250C

Port Size
Customizable from 50mm to 1200mm

Surface
Polished / Coated

Shape
Rectangular/Fabricated

Application
Pulp & Paper, Textile, Mining, Chemical, Water Treatment, Food Processing

Design Standard
MSS SP-81 / IS / BS

Bonnet Type
Standard / Extended / Fabricated

Actuation Modes
Manual / Electric / Pneumatic

Testing Standard
API 598 / EN 12266

Coating Type
Epoxy / PU / Painted

Packing Material
PTFE / Graphite

End Connection Standard
ANSI, DIN, BS, JIS

Body Design
Full Port / Reduced Port

Trim Material
SS304, SS316, Monel, Hastelloy

Operation
Lever, Gear, Handwheel, Actuator

Flow Direction
Bi-directional

Knife EDGE Gate Valve Manufacturer in India Trade Information

Minimum Order Quantity
1 Number

Delivery Time
7 Days

About Knife EDGE Gate Valve Manufacturer in India

We are the Best Knife Gate Valves manufacturer in India. FlowBiz offers versatile metallic and resilient seats with wafer, lugged, and flanged ends knife gate valves for the bidirectional and unidirectional range. Our designed Knife Edge Gate Valve provides the most trusted & durable shutoff for both wet and dry line fluid. Our bonnet-less range is ideally suited for abrasive slurries, pulp stock, semi-solids, dry ash, chips, and many more, as it is equipped with a heavy-duty gate to cut through sediments. We serve applications in paper and pulp, petrochemical industries, minerals and metals, steel plants, thermal power plants, and chemicals.

Paper & Pulp Pulp Preparation, Pulp Transfer, Stock Tower Isolation

Pneumatic Conveying, Iron Ore Slurry, Beneficiation Plant, Blast Furnace
Thermal Power Ash Handling, Coal Handling
Sugar, Chemical & General Industries Dry Solids Bagging, Hopper Dump, Pump Isolation, Silos
Cement Slurry Transfer, Dry Lime, Pneumatic Conveying
Waste Water Digester Isolation, Sludge Discharge, Sewage

FlowBiz is the best manufacturer of Knife Gate Valves in India. Knife Gate Valve Manufacturer Mumbai India. We supply Knife Gate Valves in Ahmedabad, Vapi, Valsad, Surat, Gandhidham, Kutch, Ankleshwer, Bharuch, Mumbai, Nashik, Pune, Thane, Aurangabad, Satara, Sangli, Nagpur, Kolhapur, Indore, Dewas, Bhopal, Chennai, Coimbatore, Selam and all over India.

Versatile Valve Design for Multiple Industries

Our Knife Edge Gate Valve is highly adaptable, making it suitable for demanding environments in pulp & paper, textile, mining, chemical, water treatment, and food processing industries. The rectangular or fabricated shape, customizable port sizes, and a wide selection of trim materials ensure optimum performance for handling slurry, powders, liquids, and solids at pressures up to 20 Bar.

Flexible Operation and Actuation Options

Choose the operation mode that fits your process requirements-manual, electric, or pneumatic actuation. With lever, handwheel, gear, or automated actuator operation, these valves can be integrated into a variety of industrial control systems, providing efficient isolation and flow regulation even under tough conditions.

FAQ's of Knife EDGE Gate Valve Manufacturer in India:

Q: How do I select the correct end connection standard for my Knife Edge Gate Valve application?

A: You should choose the end connection standard-ANSI, DIN, BS, or JIS-based on your existing pipeline specifications or regional requirements. Ensuring compatibility with other equipment in your facility will help prevent installation issues and maximize operational reliability.

Q: What materials are available for the trim and body of your Knife Edge Gate Valves?

A: Trim materials offered include SS304, SS316, Monel, and Hastelloy, while body options come in stainless steel, carbon steel, and alloy steel. This range allows you to match material selection to the demands of corrosive media, high temperatures, or abrasive conditions.

Q: When is it advisable to use full port versus reduced port body designs?

A: Full port valves are ideal for applications where minimal flow restriction and higher capacity are needed, such as slurry or solid handling. Reduced port designs are preferred when fluid control with less throughput is suitable, potentially saving on valve size and cost.

Q: Where are your Knife Edge Gate Valves typically used?

A: These valves find application in industries such as pulp & paper, mining, chemical processing, textile manufacturing, water treatment, and food processing. Their resilience and versatility make them suitable for handling a diverse range of media including slurry, powders, liquids, and solids.

Q: What is the process for manufacturing and testing your valves?

A: Valves are produced following MSS SP-81, IS, or BS design standards and undergo rigorous testing per API 598 or EN 12266 protocols. This ensures reliability for both soft and metal seated models, with extensive quality checks performed prior to shipment.

Q: How does the choice of actuation mode benefit my process?

A: Selecting manual, electric, or pneumatic actuation allows you to tailor valve control to your process automation. Automated actuators facilitate remote operation and precise control, while manual options are cost-effective for smaller or less automated installations.

Q: What are the usage advantages of a knife edge gate valve in slurry and powder applications?

A: The knife edge design effectively cuts through media build-up, minimizing clogging and providing tight sealing. This feature is particularly beneficial in environments with challenging materials or high particle content, reducing maintenance frequency and supporting long-term valve performance.
