AUDCO (LnT) Make Forged Steel Gate Valve

Price 9000 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

AUDCO (LnT) Make Forged Steel Gate Valve Specification

Size
15 mm to 50 mm (1/2 to 2)

Connection
Socket Weld / Screwed / Flanged

Structure
Bolted Bonnet / Welded Bonnet

Sealing
Metal to Metal, Optional PTFE/Viton

Material
ASTM A105, Stainless Steel (Optional)

Type
Forged Steel Gate Valve

Power Source
Manual

Pressure
Class 800 / Class 1500 / Class 2500

Media
Oil, Water, Gas, Steam

Working Temperature
-29°C to 425°C

Port Size
Full Bore

Surface
Smooth, Corrosion Resistant

Shape
Straight Pattern

Operation
Handwheel / Gear

Design Standard
API 602 / BS 5352

Feature
Blow-out Proof Stem

End Connection Type
Socket Weld (SW), Screwed (NPT/BSP), Flanged

Leakage Class
Class VI

Renewable Seats
Available

Testing Standard
API 598

Body Finish
Blackodized / Painted

Seat
Integral

Packing
Graphite / PTFE

Stem Type
Rising Stem

Application
Petroleum, Petrochemical, Chemical

About AUDCO (LnT) Make Forged Steel Gate Valve

AUDCO (L&T) Forged Steel Gate Valve:

Typical for Fig No. 28101/ 26301

Design Standard: API 602 / BS 5352

Design Type: Bolted body-bonnet design

Size Range: 1/4 to 2 Inch

Material of construction: A105 / F5 / F9 / F11 / F22 / F304 / F316 / LF2

End Connection: Flanged End / Socket Weld End

Pressure Rating: ASA 800# / ASA 150# / ASA 300# / ASA 600#

Testing Standard: API 598 / API 602

Versatility in Industrial Applications

Designed for demanding environments, this forged steel gate valve excels in petroleum, petrochemical, and chemical processing. Its compatibility with oil, water, gas, and steam-supported by a broad operating temperature range-makes it a reliable choice for a wide range of critical industrial processes.

Quality Assurance and Robust Construction

Conforming to API 602/BS 5352 with testing under API 598, this valve embodies durability and safety. Its corrosion-resistant, blackodized or painted finish ensures longevity, while blow-out proof stems and metal-to-metal or optional PTFE/Viton sealing deliver consistent leak-free performance even at high pressures.

Flexible Connection and Customization Options

With multiple end connection types-Socket Weld, Screwed (NPT/BSP), and Flanged-this valve meets varied installation needs. Material options, stem packing choices, and renewable seats provide further customization, ensuring optimal compatibility and maintainability in any configured system.

FAQ's of AUDCO (LnT) Make Forged Steel Gate Valve:

Q: How does the AUDCO (LnT) Forged Steel Gate Valve ensure leak-proof operation?

A: The valve is designed with metal-to-metal sealing and optional PTFE or Viton seals, providing excellent leakage protection. Its Class VI leakage rating and blow-out proof stem structure enhance overall sealing performance, making it suitable for high-pressure applications.

Q: What types of end connections are available for this gate valve?

A: This gate valve is offered with Socket Weld (SW), Screwed (NPT/BSP), and Flanged end connections. These options allow for flexible installation across various pipeline designs common in industrial processes.

Q: When should renewable seat options be considered?

A: Renewable seats are recommended when frequent maintenance or replacement may be necessary due to the severity of the application, such as in harsh or abrasive media, ensuring prolonged valve service life and reduced downtime.

Q: Where is this type of valve typically installed?

A: These forged steel gate valves are typically installed in petroleum refineries, petrochemical plants, chemical processing facilities, and other settings dealing with oil, water, gas, or steam pipelines demanding robust shut-off and precise flow control.

Q: What are the benefits of the rising stem and blow-out proof stem features?

A: The rising stem allows clear visual indication of valve position, enabling safer operation and maintenance. The blow-out proof stem design ensures enhanced safety by preventing accidental ejection under pressure, making it ideal for critical service conditions.

Q: How is the valve tested before shipping?

A: Each gate valve is tested in accordance with API 598 standards, verifying its sealing performance, structural integrity, and pressure resistance to ensure it meets rigorous industrial quality requirements.
