Swing Check Valve Manufacturer in Gandhinagar

Send Inquiry

Request To Call Back

Swing Check Valve Manufacturer in Gandhinagar

Price 800 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

Swing Check Valve Manufacturer in Gandhinagar Specification

Material
Cast Iron / Ductile Iron / Stainless Steel

Connection Type
Flanged / Screwed / Socket Weld

Control System
Automatic flow control (non-return)

Features
Corrosion resistant, Maintenance free, Low pressure drop, Leakproof

Valve Type
Check Valve

Valve Size
DN15 to DN300

Application
Industrial pipeline systems, water supply, wastewater treatment, chemical processing

Structure
Swing

Sealing
EPDM / NBR / PTFE

Type
Swing Check Valve

Power
Manual

Pressure
PN10 / PN16

Media
Water, Oil, Gas, Steam

Port Size
1/2 inch to 12 inch

Temperature
-10C to 80C

Disc
Stainless Steel / Bronze

Pin
Stainless Steel

Installation Position
Horizontal / Vertical (upward flow only)

Weight
Varies as per size (consult manufacturer)

End Connection Standard
ANSI / DIN / BS

Face to Face Dimension
As per EN 558-1 / IS:5312

Body Coating
Fusion Bonded Epoxy / Paint

Color
Blue / Green / As per customer requirements

Inspection & Testing
As per API 598 / IS:12235

Flow Direction
Uni-directional

Opening Pressure
Low opening pressure

About Swing Check Valve Manufacturer in Gandhinagar

Introduction:

FlowBiz Export Private Limited is a renowned manufacturer and supplier of Swing Check Valve in Gandhinagar, India. FlowBiz has established itself as a trusted name in the valve manufacturing industry with a strong focus on quality, innovation, and customer satisfaction.

Applications

Swing check valves can regulate and transport water, steam, oil, nitric acid, acetic acid, solid oxidizing medium, and other corrosive media. They are usually installed in pipelines for petroleum, chemicals, and water-based process flows. They suit clean fluid, not solid-particle-laden or viscosity-intensive media.

Swing check valves are a standard solution in a variety of industries. Power plants, gas transmission, and refineries frequently employ swing check valves. Swing check valves help control the improper flow of gas that could result in dangerous leaks or fires. These valves have broad usage in gas pipelines ï both in cleaning, distribution, and compression.

Since swing check valves work well with large, predictable flow, they are frequently used in wastewater treatment and water pumping.

Generally, for clean process media, swing check valves offer good service.

We are a Manufacturer, Supplier, and Exporter of Swing Check Valve in Rajkot, Ahmedabad, Vapi, Valsad, Surat, Gandhidham, Kutch, Ankleshwer, Bharuch, Mumbai, Nashik, Pune, Thane, Aurangabad, Satara, Sangli, Nagpur, Kolhapur, Indore, Dewas, Bhopal, Chennai, Coimbatore, Selam and all over India.

Precision Engineering & International Standards

Our swing check valves adhere to ANSI, DIN, and BS end connection standards. With strict compliance to EN 558-1 and IS:5312 face-to-face dimensions, and rigorous inspection as per API 598 and IS:12235, customers can rely on consistent performance and global compatibility.

Versatile Coating & Material Choices

We provide both fusion bonded epoxy and painted body coatings to ensure superior corrosion resistance and durability. Valves are available in cast iron, ductile iron, and stainless steel, with stainless steel or bronze discs and seals in EPDM, NBR, or PTFE, catering to various operating conditions and media.

Application Flexibility & Easy Installation

Designed for manual operation and uni-directional flow, our swing check valves are suitable for water, oil, gas, and steam systems. They are compatible with flanged, screwed, or socket weld connections, supporting flexible installation in horizontal or vertical pipelines with upward flow.

FAQ's of Swing Check Valve Manufacturer in Gandhinagar:

Q: How should swing check valves be installed to ensure proper operation?

A: Swing check valves should be installed in horizontal pipelines or in vertical pipelines with upward flow only. This positioning ensures that the valve functions correctly, preventing reverse flow and allowing the disc to swing freely with minimal resistance.

Q: What media can these swing check valves be used with?

A: Our swing check valves are designed for use with water, oil, gas, and steam across a variety of industrial processes, including water supply, wastewater treatment, and chemical applications.

Q: When is it necessary to select a specific sealing material for the valve?

A: Sealing material selection (EPDM, NBR, or PTFE) depends on the type of media and operating temperature. For instance, PTFE is ideal for aggressive chemicals and higher temperatures, while EPDM and NBR are generally used for water, oil, or standard industrial conditions.

Q: Where can these swing check valves be applied in industrial systems?

A: They are suitable for industrial pipeline systems, water supply networks, wastewater plants, and chemical processing facilities, providing non-return capabilities and automatic flow control wherever unidirectional flow is required.

Q: What is the process for inspecting and testing these valves?

A: Inspection and testing are conducted as per API 598 or IS:12235 standards. This ensures each valve meets stringent quality, performance, and leak-tightness criteria before delivery to customers.

Q: What benefits do clients gain from using your swing check valves?

A: Customers benefit from a maintenance-free, leakproof design that resists corrosion, provides low pressure drop, and ensures reliable, automatic non-return flow control-maximizing operational safety and minimizing downtime.
