PTFE Lined Ball Valve Manufacturer in India

Price 2000 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

PTFE Lined Ball Valve Manufacturer in India Specification

Pressure
Class 150 lbs / PN10 / PN16

Caliber
Full Bore / Reduced Bore

Structure
Floating Ball, Two Piece / Three Piece

Channels
2

Connection
Flanged (ANSI, DIN, JIS Standards)

Material
PTFE Lined (Body: Ductile Iron / Carbon Steel / Stainless Steel options available, Lining: PTFE)

Power
Manual / Pneumatic / Electric

Media
Acids, Corrosive Liquids, Chemicals

Temperature of Media
-29C to +180C

Port Size
15mm to 300mm

Flange
ANSI B16.5 / DIN / JIS

Finish
High Gloss / Corrosion Resistant Coating

Application
Chemical, Petrochemical, Pharmaceutical, Water Treatment

Shell Test Pressure
Hydrostatic / Pneumatic

Antistatic Feature
Available

Certificates
ISO 9001:2015 / CE Marking / ATEX Certified

Face to Face Dimension
ASME B16.10

Maintenance
Low, Suitable for Inline Maintenance

Fire Safe Design
Optional as per API 607

Flow Direction
Bidirectional

Blowout Proof Stem
Standard

Color
Blue / Customized

Cavity Pressure Relief
Available

Operation
Lever Operated / Gear Operated / Actuator Operated

Leakage Class
Class VI

Seat
RTFE / PTFE / TFM

Design Standard
ASME B16.34 / BS 5351

Body Test Pressure
1.5 times Design Pressure

End Connection
Flanged Ends

About PTFE Lined Ball Valve Manufacturer in India

PTFE Lined Ball Valve

The interior is fully lined with a high-quality PTFE or PFA lining fabric, and due to its thickness, it ultimately rescues the valves against any chemical corrosion, which makes it a perfect choice for any nasty applications.

They are also known as shut-off valves as some brands are planned to include a free-floating ball design that enables Positive shutacross the force range, for example, the Flowserve Atomac Lined Ball Valve range.

MVS lined Ball Valve is generally made from Cast Ductile Iron with lining. PTFE Lined Ball Valves is a Full Port, Two Piece Split Body Design, Bolted Body Construction with an Integral Ball and Stem Unit.

Functions

A Lined Valve is also known as a shut-off valve. It gets its name from the feature which enables auto shut-off when a specific pressure range is reached. This is primarily a function toprevent leakage, combustion, and explosions. A Lined Valve is made of a body, stem, ball, seat, and lining.

Superior Corrosion Protection

PTFE lined ball valves excel at isolating aggressive chemical media. The PTFE lining resists corrosive attacks common in processing acids or chemicals, ensuring a longer lifespan and reduced maintenance cycles even in the harshest environments.

Compliance with Global Standards

Manufactured under stringent norms like ASME B16.34, BS 5351, and API 607 (fire safe option), these valves meet or exceed international requirements. They feature comprehensive certifications such as ISO 9001:2015, CE Marking, and ATEX, making them suitable for regulated industries worldwide.

Flexible Operation and Maintenance

Operators can choose manual, pneumatic, or electric actuation. Inline maintenance is straightforward due to the floating ball design and blowout-proof stem, minimizing downtime. Multiple end connections and port sizes enhance system compatibility.

FAQ's of PTFE Lined Ball Valve Manufacturer in India:

Q: How does the PTFE lining provide corrosion resistance in ball valves?

A: PTFE linings create an inert barrier between the valve body and media, preventing chemical reactions and corrosion. This protection is essential for handling aggressive substances such as acids and corrosive liquids in chemical and pharmaceutical applications.

Q: What operation methods are available for these PTFE lined ball valves?

A: These valves can be operated manually via lever, mechanically with a gear, or automatically using an actuator, enabling flexible integration into various process control systems depending on operational needs.

Q: When should I choose a fire-safe design for my application?

A: Select a fire-safe design as per API 607 if your process involves flammable media or operates in environments with fire risk. Fire-safe valves prevent external leakage during fire incidents, enhancing plant safety.

Q: Where can these ball valves be installed, and what industries commonly use them?

A: PTFE lined ball valves are installed in chemical plants, petrochemical refineries, pharmaceutical production facilities, and water treatment systems. Their corrosion resistance makes them ideal wherever aggressive or hazardous media is present.

Q: What is the process for maintaining PTFE lined ball valves?

A: These valves require minimal maintenance and are suitable for inline servicing. Regular inspection for seal integrity and periodic operation checks ensure long-term performance without frequent removal or shutdown.

Q: What benefits do certifications like ISO 9001:2015, CE Marking, and ATEX provide?

A: These certifications assure product quality, safety, and compliance with international standards. It builds trust among users and helps meet regulatory requirements in global or safety-critical markets.
