Pneumatic Operated Wafer Type Butterfly Valve PN-10

Price 23000 INR/ Number

Get a Price/Quote

MOQ : 1 Unit

Pneumatic Operated Wafer Type Butterfly Valve PN-10 Specification

Connection
Wafer Type

Valve Type
Butterfly Valve

Material
Cast Iron with Disc and Seat options

Power Source
Pneumatic

Pressure
PN-10

Media
Air Water Gas Oil

Working Temperature
-10C to 80C

Port Size
Available in multiple sizes

Shape
Round Butterfly

Warranty
12 months

About Pneumatic Operated Wafer Type Butterfly Valve PN-10

Specifications

End Connection : Wafer - API 609 (CAT - A)

Range : DN40 - DN300

Suitable : ASMI B16.5 150#

Pressure Range : PN10, PN16

Leakage Class : 100% Tightness at fully differential pressure

Standard : API 609, BS 5155, ISO 5211, API 598, ASME B16.5

Body Material : Cast Iron(CI), SGI, WCB, CF8, CF8M

Disc Material : SGI, CF8, CF8M, WCB

Stem Material : SS410, SS304, SS316

Body Liner / Seat Material : NBR, EPDM, VITON, SILICONE, PTFE

Shaft Bearing Material : PTFE

Robust Construction and Versatility

Crafted with cast iron and available disc and seat options, this butterfly valve ensures longevity and compatibility with air, water, gas, and oil. Its round wafer type design enables straightforward installation in pipelines, and the pneumatic actuation supports rapid and efficient operation, perfect for demanding industrial environments.

Optimized for Multiple Applications

With pressure handling up to PN-10 and a working temperature range from -10C to 80C, this valve meets the requirements of plumbing, chemical, and oil and gas sectors. Thanks to its modular sizing and reliable sealing, users can adapt it confidently for any flow control challenges.

FAQ's of Pneumatic Operated Wafer Type Butterfly Valve PN-10:

Q: How is the Pneumatic Operated Wafer Type Butterfly Valve installed?

A: This valve is mounted between flanges using the wafer-type end connection, ensuring quick and secure installation within pipeline systems without extensive modifications.

Q: What are the primary benefits of choosing this butterfly valve for industrial applications?

A: Key advantages include reliable pneumatic actuation for swift operation, robust cast iron construction for long service life, broad media compatibility, and a 12-month warranty for peace of mind.

Q: When should I use this valve for flow control?

A: The valve is ideal for controlling air, water, gas, and oil in pipelines when you require dependable shutoff and regulation at pressures up to PN-10 and temperatures from -10C to 80C.

Q: Where can this butterfly valve be used effectively?

A: It is suitable for use in industrial sectors such as water treatment plants, power stations, chemical processing, and oil & gas installations, where precise flow regulation is essential.

Q: What is the process of operating the valve with pneumatic power?

A: Compressed air is supplied to the pneumatic actuator, which rotates the valve's disc to open or close the flow path, allowing for remote and automatic control.

Q: What options are available for the disc and seat materials?

A: The valve offers various disc and seat material options, enabling customization according to specific requirements like chemical compatibility or enhanced wear resistance.

Q: How does the warranty support enhance product reliability?

A: A 12-month warranty ensures timely assistance in case of manufacturing defects, affirming the valve's durability and the manufacturer's commitment to quality.
